Product parameter | CPU | 2.0GHz Octa-core |
Operating System | Android™ 9.0 | |
Memory | 8GB | |
Storage | 256GB | |
Display | 13.3′ | |
Resolution | 1920*1080 | |
Front camera | 8MB Front | |
Rear camera | 13MP Rear | |
Battery | 71140mWh | |
Operating temperature | 0~50℃ | |
Storage temperature | -20~70℃ | |
VCI Connection | Wi-Fi/BT/USB | |
VCI Connector | SmartLink C | |
Product Features | Full System Diagnosis | ● |
Auto VIN Identification | ● | |
Reset Functions | 33 | |
Actuation Test | ● | |
VW & AUDI Guided Function | ● | |
Coding | ● | |
Programming | ● | |
Maintenance information | ● | |
Remote diagnosis | ● | |
FCA | ● | |
J2534 | ● | |
D-PDU | ● | |
DoIP | ● | |
CAN FD | ● | |
Topology | ● | |
ADAS Calibration | ● | |
Osciloscope | ● | |
Videoscope | ● | |
BST360 Battery Tester | ● | |
X-431 TSGUN TPMS device | ● | |
X-431 S2-2 Sensorbox | ● | |
X-PROG 3 Immobilizer | ● | |
Mall | ● |
Features
- Full system vehicle coverage for U.S., Asian and European markets over 110 brands, which is continually updated
- Upgrade and expand the X-431 PAD VII with more software and service via the new module ‘MALL’ as demanded
- Real-time voltage display helps technician to monitor the voltage condition of vehicle during the diagnosis
- Topology mapping gives a visual checking on DTCs and all systems communication status
- Support automotive communication protocols CAN/CANFD/DoIP and automotive communication standards J2534/D-PDU/RP1210
- Auto-detects the communications protocol of the vehicle and assist to check automotive OBDII port pin damaged or not
- Intelligent diagnostic enable identify VIN automatically and access system quickly
- Guided function for VW and AUDI
- Optional ADAS calibration function increases more revenue
- Advanced coding and programming function
- An extended solution to support TPMS service
- 2.4GHz & 5GHz dual band communication ensures quick and stable connection
- Empower technician to diagnose light, medium & heavy duty vehicles with Smarlink C
- The basic functions include read & clear DTC, remote diagnosis, Bi-directional control, live data graph, wireless software update etc.
- Build-in repair information and training video modules help to track and fix issue fast
Advantages
- Larger memory (8GB), smoother operation; strong light readable screen; support for three defenses
- Support 9 kinds of module expansion such as oscilloscope, sensor, battery, tire pressure gun, endoscope, PRO G3, etc.
- Support smartlink remote diagnosis
- Support D-PDU/J2534/RP1210 diagnostic standard, CAN/CAN FD/DOIP protocol.
